15kva Three Phase Dry Type Electrical Isolation Transformer China Manufacturer

15kva Three Phase Dry Type Electrical Isolation Transformer

$99-9999 /Set/Sets

Sample:

$100.00 /Set/Sets, 1 Set/Sets (Max. Order)
Buy Sample

Product Description

Luoyang Datang Energyphotoelectron. It is an integrated enterprise that engages in product research and development, sales, and import and export services. Complete production equipment, complete testing methods, strong technical force, and complete qualifications. We can provide various Medium and high-voltage transformers, including oil immersed Distribution transformers and Dry Type Distribution transformers. Voltage Transformers include three-phase isolation transformers, single-phase control transformers, Transformer Accessories, and other products. Voltage, specifications, and other parameters can be customized according to customer requirements. Welcome to leave a message for consultation.

Instrument for isolating transformer

The dry-type Isolation Transformer is widely used in circuits with AC 50Hz to 60Hz and voltage below 660V. Luoyang Datang EnergyPhotoelectron’s products can be custom-designed based on user requirements, including input and output voltages, connection configurations, the number and location of tap-changing devices (generally ±5%), the distribution of winding capacities, the configuration of secondary single-phase windings, the use of rectifier circuits, and whether a case is required. The company carefully tailors its products to meet specific needs.

Technical indicators

1. Input rated voltage: three-phase 380V or single-phase 380V or single-phase 220V

2. Operating frequency: 50Hz – 60Hz

3. Efficiency: ≥ 95%

4. Temperature rise:<60

5. Waveform distortion:<0.1%

6. High voltage test: 2500V, no breakdown for 1 minute

7. Insulation resistance: winding resistance to ground insulation resistance ≥ 500M Ω; Primary to secondary insulation resistance ≥ 500M Ω

Product Attributes

Model No.: SG

Brand: PDDN

Place Of Origin: China

Use: Power, Current, Electronic, High Frequency, Lighting, Audio, Potential, Instrument, Rectifier, Pulse, Reactor

Phase: Three, Single

Coil Structure: Toroidal

Number Of Coils: Autotransformer

Product Name: Dry type isolation transformer

Rated Capacity: 1kva~2000kva

Rated Voltage: 110V 220V 240V 380V 400V 480V 660V

Rated Power: 1kw~2000kw

Frequency: 50Hz/60Hz

Insulation Class: F / H

Cooling Mode: AN/AF

Core Material: Cold rolled steel sheet

Core Type: E

Protection Mode: Shell
