Oil Immersed Transformer

The oil-immersed Transformer is to use electromagnetic induction to convert AC voltage. Because of its safety, reliability, and efficiency advantages, it is widely used in industrial, commercial, and urban distribution networks.

The structure of an oil-immersed transformer is composed of an iron core, winding, oil tank, radiator, valve, and other parts. During its working process, when the input AC voltage changes, the magnetic field in the iron core changes, causing the current in the winding to change, thereby generating an induced electromotive force. This induced electromotive force is opposite to the polarity of the input voltage, which can offset the input voltage change and keep the output voltage stable.

Function Principle of Oil Immersed Transformer

The central part of an oil-immersed transformer is an iron core with a winding surrounded by insulating Oil. When current passes through the winding, a magnetic field is generated, which in turn generates a vortex electric field in the iron core. This electric field causes the iron molecules in the iron core to arrange in an orderly manner in a specific direction, forming a magnetic flux.

Advantages and Characteristics of Oil Immersed Transformer

• Stability: The use of insulating Oil in Oil immersed transformers can effectively prevent the erosion of moisture, oxygen, and other substances inside the Transformer, thereby improving the stability and service life of the equipment.
• Fire resistance: The oil-in-oil immersed transformers can effectively suppress the generation of arcs. Once there is an internal fault in the equipment, the Oil can quickly extinguish the arc and reduce the possibility of fire.
• Easy maintenance: The internal parts of the Oil-involved Transformer are soaked in Oil, making maintenance relatively straightforward as the internal condition of the Transformer can be directly observed.
• Good heat dissipation: Insulation Oil can conduct the heat generated during transformer operation and dissipate the heat into the air through natural convection, allowing the Transformer to operate at higher loads.

Application of Oil-immersed Transformer

1）Power system: Oil-immersed transformers are widely used in power system transformation and distribution stations and are mainly responsible for power transmission and distribution, voltage reduction, and voltage boosting. Due to its stable performance, reliable operation, small size, and high power, oil-immersed transformers have become an indispensable piece of equipment in the field of power transmission and distribution.

Oil immersed transformers used in power distribution systems

2）Industrial field: Oil-immersed transformers are widely used in the industrial field, mainly used to provide stable and reliable power for various large machinery and equipment, such as motors, air conditioners, lighting, etc. At the same time, it can also be used in power frequency conversion control systems to adjust the frequency to adapt to different working environments. In addition, it can also be used in fields such as power equipment and lighting equipment, such as welding machines, motors, and lighting power supplies, to play the role of power conversion and electronic equipment protection.

Oil immersed transformers are used in the industrial field

3）Logistics, transportation, and other fields: Because oil-immersed transformers are smaller in size and lighter in weight, they are also widely used in logistics, transportation, and other fields. For example, it can provide stable power support for various mobile generator sets, giant stage lighting and audio equipment, etc.

The Main Advantages of Oil-immersed Transformer

• High safety: Since the Oil of the oil-immersed Transformer is isolated from the outside world, even if the Transformer is overloaded, short-circuited, or overheated and other abnormal conditions occur, it will not cause danger such as fire or explosion.
• High reliability: The oil-immersed Transformer has a self-protection mechanism. When an abnormal situation occurs, the oil temperature will rise, but the Transformer will not be damaged immediately. At the same time, the oil-immersed Transformer also has a long service life, which can generally be used for more than 20 years.
• High efficiency: Since the loss of the oil-immersed Transformer is low, it is highly efficient and can save energy.
• Easy maintenance: Due to the simple structure of the oil-immersed Transformer, it is easy to maintain. It only needs to regularly check the quality of the Oil and replace the filter element.
