Three phase oil immersed distribution transformer

$660-25000 /Set/Sets

Option:

100KVA-11KV/0.4VA

200KVA-22KV/0.415KV

250KVA-15KV/0.415KV

300KVA-33KV/0.4KV

400KVA-13.8KV/0.4KV

500KVA-12.5KV/0.415KV

Sample:

$699.00 /Set/Sets, 1 Set/Sets (Max. Order)
Buy Sample

Product Description

THE PRODUCT BRIEF INTRODUCTION:

Oil Immersed Transformers of 1000kVA and above shall be equipped with outdoor signal thermometers and can be connected with remote signals. Oil-immersed transformers of 800kVA and above shall be equipped with gas relays and pressure protection devices, and oil-immersed transformers of less than 800kVA may also be equipped with gas relays according to the use requirements. Dry-type transformers shall be equipped with temperature measuring devices according to the provisions of the manufacturer, generally for transformers of 630kVA and above. Product classification can be divided into three-phase transformers and single-phase transformers according to the number of phases of a single transformer. In the three-phase power system, three-phase transformers are generally used. When the capacity is too large and limited by transportation conditions, three single-phase transformers can also be used in the three-phase power system to form a transformer group. In our company, we have a Oil Type Distribution Transformer, Conservator Type Transformer, and Electric Furnace Transformer.

Company OverviewLuoyang Datang EnergyPhotoelectron is a comprehensive enterprise integrating product research and development, product sales, and import and export services. It has more than 45 years of R&D experience. The company has more than 120000 square meters of modern workshops, research and development centers, and more than 30,000 square meters of employee apartments. Complete production equipment, complete testing methods, strong technical force, and complete qualifications. We can provide all kinds of high, medium, and low voltage transformers with a voltage of 110KV and below and a capacity of 120000kVA and below for various purposes. The parameters and specifications can be customized according to customer requirements. The products have been sold to Korea, Japan, Russia, Vietnam, Myanmar, Singapore, Malaysia, Iraq, Zambia, Congo, South Sudan, Ethiopia, Nigeria, South Africa, Azerbaijan, Zimbabwe and other countries.

Product Attributes

Model No.: Oil immersed transformer

Brand: PDDN

Place Of Origin: China

Use: Power, Electronic, Lighting, Audio, Potential, Instrument, Rectifier, Pulse, Reactor

Phase: Three

Coil Structure: Toroidal

Number Of Coils: Autotransformer

Product Name: Oil immersed distribution transformer

Rated Capacity: 30kva~2500kva

Rated Primary Voltage: 6kv/10kv/11kv/13.8kv//15kv/20kv/22kv/33kv/35kv/

Rated Secondary Voltage: 380v/400v/415v/420v

Rated Power: 20kw~2000kw

Frequency: 50Hz/60Hz

Insulation Class: A

Cooling Mode: ONAN

Connection Group Number: Dyn11/Dyn0

Core Material: Copper / aluminum
