Steel core aluminum stranded cable China Manufacturer

Steel core aluminum stranded cable
Get Latest Price

Option:

BS 215-2，BS EN 50182，IEC 61089，ASTM B 232/B ，

Sample:

$0.00 /Meter, 1 Meter (Max. Order)
Buy Sample

Product Description
ACSR conductors in steel core aluminum stranded cables are widely used for long-distance power transmission because they are ideal for long overhead line crossings. They are also used as conveyor belts to support overhead wires. Comply with BS 215-2/BS EN 50182/IEC 61089/ASTM B 232/B 232M/DIN 48204/JIS C 3110 standards.ACSR conductor of steel core aluminum stranded cable is composed of several aluminum and galvanized steel conductors, which are twisted in concentric layers. The wires that make up the iron core are made of galvanized steel material, and their outer layer is covered with aluminum material. The galvanized iron core generally consists of 1, 7, or 19 conductors. The diameters of steel and aluminum wires can be the same or different.By changing the relative ratio of aluminum to steel, the properties required for any particular application can be achieved. Higher antistatic performance can be achieved by increasing the content of steel, and higher current carrying capacity can be achieved by increasing the range of aluminum.Luoyang Datang EnergyPhotoelectron is a comprehensive enterprise integrating product research and development, product sales, and import and export services: complete production equipment, complete testing methods, strong technical force, and complete qualifications. We can provide various Medium and high-voltage transformers, including oil-immersed and Dry Type Distribution transformers. Voltage Transformers include three-phase isolation transformers, single-phase control transformers, Transformer Accessories, and other products. Voltage, specifications, and other parameters can be customized according to customer requirements. Welcome to leave a message for consultation.

Product Attributes

Model No.: BS 215-2

Brand: PDDN

Place Of Origin: China

Conductor Material: Copper, Aluminum

Insulation Materials: Pvc, Xlpe

Jacket: Pe, Pvc

Usage: Transmission and distribution engineering

Product Certification: iso9001

Processing Customization: yes

Sheath Material: Cross-linked polyethylene insulation PVC sheath

Insulating Material: Plastic insulated power cable

Colour: black

Core Material: Oxygen-free copper / aluminium

Service Life: 30-70 years

Service Temperature: 90 °C

Material Aging: slow
