Oil Transformer Oil level measurements China Manufacturer

Oil Transformer Oil level measurements

$10-200 /Piece/Pieces

Payment Type:	L/C,T/T,D/P,D/A,Paypal,Money Gram,Western Union,D/A
Incoterm:	FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP,DDU,Express Delivery,DAF,DES
PDDN-Min. Order:	5 Piece/Pieces
PDDNansportation:	Ocean,Land,Air,Express,Express

Option:

UHZ-02

BSW-70

YZ-70

YZF1

YZF2

YZ-70

Sample:

$20.00 /Piece/Pieces, 1 Piece/Pieces (Max. Order)
Buy Sample

Product Description

Luoyang Datang Energyphotoelectron. The company deals in the R&D, manufacturing, and sales of various medium, high, and Voltage Transformers and Transformer Accessories. The transformer accessories mainly include Buchholz Relay, Tap Changer, oil level gauge, Butterfly Valve, Moisture Absorber, pressure reducing valve, Cross Flow Cooling Fan, Bimetal Thermometer, Epoxy Resin Insulator, etc. New and old customers are welcome to purchase and customize.

The basic structure of oil level gauge

The Pointer Oil Level Gauge (from now on referred to as the oil level gauge) applies to the oil level display of the Oil Immersed Transformer oil conservator and on-load tap changer oil conservator as well as the alarm of the lowest and highest limit oil level.

The oil level gauge is mainly composed of the display part composed of a pointer and dial, the alarm part consisting of the magnet (or cam) and switch, and the transmission part consisting of a reversing and variable speed gear set, swing rod, and float ball.

Installation of oil-level juice

An oil-level gauge with a floating ball-shaped swing rod should be installed in the center of the end cover of the oil conservator, and the swing rod should swing radially. Other oil level gauges with floating ball-type swing rods should be installed at the lowest oil level in the oil conservator. The telescopic rod-type oil level gauge for the diaphragm oil conservator shall be installed at the highest oil level of the oil conservator. During the installation of the oil level gauge, it must be ensured that the movable space of the swing rod and the floating ball is not interfered with by any structure.

Inspection before installation of oil level gauge

Before installation, check whether the oil level gauge is damaged and rusted during storage and transportation, and install it after treatment.

Before installing the oil level gauge, gently and slowly pull the swing rod to rotate flexibly and reliably and signal at the extreme position.

Before installing the oil level gauge, check whether the lead cable, outlet terminal, and signal switch are well insulated.

Maintenance of oil level gauge

The oil level gauge shall be checked once a year during operation. Check whether the lead wire and switch are well insulated and whether the sealing gasket needs to be replaced.

FAQ

1. Are you a trading company or a manufacturer? We are a company integrating production and marketing, industry and trade! 2. What kind of grounding material do you produce? Including Epoxy resin insulators, Power Cables, high voltage disconnectors, Power Distribution Cabinets, Oil Immersed Transformers, dry type transformers, Transformer Accessories, etc. 3. Are customized materials available? Yes, please provide the specifications you need. 4. Do you accept OEM services? yes! 5. What is your delivery time? Usually 20-25 days, please confirm with us before ordering! 6. What is payment Trems? Generally, 50% is the deposit and 50% is before the bill of lading is sent by wire transfer. 7. How to package the product? Usually, in a steel tray. We will do it according to customers’ requirements. 8. What is the loading port available to you? Usually Ningbo Port or Shanghai Port.

Product Attributes

Model No.: YZF3-250,YZF2-200,YZS3-200

Brand: PDDN

Warranty Period: 3 Years

Certification: Csa, Pcoc, Reach, Iecee, Scoc, Ul, Epa, Gs, CE/CCC

Support Customization: Oem, Odm

Place Of Origin: China

Product Name: Pointer type oil level gauge

Type: YSF/YZS

Ambient Temperature: -40°C~+50°C

Texture Of Material: Metal

Temperature Range: ＜90%(at 20 ℃)

Applicable To Oil Tank Diameter: 800mm-1600mm

Installation Flange Opening: 80mm-130mm

Float Diameter: 80-125mm

Waterproof Performance: IP55

Packaging & Delivery

PDDN-Selling Units	:	Piece/Pieces
PDDN-Single package size	:	15cm*20cm*15cm
PDDN-Single gross weight	:	1.8kg
Package Type	:	PDDN-Carton
Picture Example	:
