Overview of Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber

Transformer accessories refer to various auxiliary equipment or materials used in conjunction with transformers to assist them in achieving their functions. Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber is crucial for the regular operation of transformers, as they can ensure stable operation under various environmental conditions and improve the efficiency and reliability of transformers. At the same time, the mintenance and upkeep of transformer accessories are also important links to ensure the normal operation of transformers, and regular inspections and replacements are needed to ensure their normal operation. Transformer accessories are essential auxiliary equipment and materials for the regular operation of transformers and are of great significance for stable operation and efficiency.

Transformer Accessories Mainly Include the Following Types

Transformer oil: used for insulation and cooling.

Transformer oil conservator: stored transformer oil and maintained a stable oil level.

Radiator: Used to transfer the heat generated by the transformer to the surrounding air and maintain stable transformer temperature.

Respirator: used to regulate the internal gas pressure of the transformer and prevent deformation of the transformer oil tank.

Explosion-proof tube: used to prevent the gas and oil flow generated in the event of internal faults in transformers from spraying out.

Insulation sleeve: used to protect the windings and leads of transformers, preventing electric shock and short circuits.

Thermometer: used to monitor the temperature of transformers and detect abnormal situations promptly.

Gas relay: used to monitor the pressure and temperature of the gas inside the transformer and detect faults promptly.

Voltage and current transformers: Used to convert transformers’ voltage and current signals into measurable electrical signals.

Lightning arrester: used to protect transformers from lightning and overvoltage impacts during operation.

Specifications of Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber

This moisture absorber protects oil-immersed transformers. Water inside a transformer causes big problems. It damages insulation. It also makes the oil break down faster. This device stops that. It uses special orange silica gel beads. These beads soak up water vapor very well. You see them inside the unit. The bright orange color is important. It shows the gel’s condition clearly.

The unit has two chambers. This is the “double breathing” part. Air moves in and out through the lower chamber first. Moisture gets trapped there. Then, drier air passes into the transformer tank. This design stops moisture from getting back inside. It keeps the transformer oil much drier. Dry oil protects the transformer better. It makes the whole system last longer.

The silica gel beads change color as they work. Dry beads are deep blue. As they absorb water, they turn lighter blue. Eventually, they become bright orange. Orange means the gel is full of water. It needs replacing. This color change is easy to see. Staff can check it quickly. They know exactly when to service the unit. This prevents moisture problems before they start.

The unit mounts directly onto the transformer. It connects to the conservator tank or breather pipe. Installation is usually simple. Maintenance is straightforward too. Staff just replace the saturated gel. They use fresh, dry orange silica gel. This keeps the protection working. The unit handles transformer oil contact safely. The materials are oil-resistant. They won’t break down. The housing is tough. It protects the gel inside. This is reliable protection for critical equipment.

Applications of Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber

Orange silica gel particles are key parts in double breathing moisture absorbers for oil-immersed transformers. Transformers need clean, dry oil to work well. Moisture in the oil causes big problems. Moisture reduces the oil’s insulating power. This can lead to electrical failures. Moisture also speeds up oil aging. It causes corrosion inside the transformer tank. The double breathing system fights this moisture.

Air enters the transformer as oil cools. Air leaves as oil heats up. Normal air contains water vapor. The double breathing absorber sits in the air path. It uses silica gel to trap moisture before air gets inside the transformer. The orange silica gel acts like a powerful sponge. It pulls water vapor directly from the air passing through the breather. This keeps the air entering the transformer dry.

The bright orange color is important. Fresh silica gel is deep orange. As the gel absorbs water, it changes color. It turns green when saturated. This color change is a clear visual signal. Operators see the green color easily. They know it’s time to replace the silica gel. This indicator function prevents ineffective moisture protection. Regular replacement ensures continuous moisture control.

Using orange silica gel protects the transformer oil. Dry oil maintains its high insulating strength. Dry oil also lasts longer. It prevents sludge formation. Controlling moisture stops internal rusting. This reduces costly maintenance. It helps avoid unexpected transformer outages. The double breathing system with orange silica gel is a simple guard. It protects the transformer’s health and reliability for years.

Company Profile

PDDN Photoelectron Technology Co., Ltd. is one of the leading enterprises in power electronics technology and power products, which is fully involved in developing solar inverters， transformers, voltage regulators, distribution cabinets, thyristors， modules， diodes， heaters, and other electronic devices or semiconductors. We will be committed to providing users with high-quality, efficient products and considerate service.

It accepts payment via Credit Card, T/T, West Union, and Paypal. PDDN will ship the goods to customers overseas through FedEx, DHL, by sea, or by air. If you want high-quality Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber, please send us inquiries; we will be here to help you.

Payment Methods

L/C, T/T, Western Union, Paypal, Credit Card etc.

Shipment

By sea, by air, by express, as customers request.

Storage Conditions

1) Store in a dry environment at room temperature.

2) Avoid damp and high temperature.

3) Use immediately after opening the inner packing bag.

5 FAQs of Orange Silica Gel Particles Oil-Immersed Transformer Accessories Double Breathing Moisture Absorber

What are Orange Silica Gel Particles?

These orange beads are the main part inside a double breathing moisture absorber for oil transformers. They soak up water vapor from the air entering the transformer tank. This keeps the insulating oil dry. Dry oil protects the transformer better.

How does this moisture absorber work?

The absorber connects to the transformer’s breather pipe. Air going in or out must pass through the silica gel chamber. The orange silica gel traps moisture from this air. This stops water from getting into the oil. It helps maintain the oil’s quality.

Why does the silica gel change color?

Fresh silica gel is bright orange. As it absorbs water, the color slowly changes. It turns darker, eventually becoming green or dark blue. This color change is a clear sign. It shows the silica gel is getting full of moisture. It needs replacement soon.

When should I replace the silica gel?

Replace the silica gel when most beads turn dark green or blue. The exact time depends on the air humidity around the transformer. Check the color regularly. Replace it before it stops absorbing moisture effectively. This prevents wet air from reaching the oil.

Is the silica gel safe for the transformer?

Yes, the silica gel is completely safe. It is chemically inert. It does not react with the transformer oil. The beads are tough. They do not break down into dust. They only absorb water vapor from the air passing through the breather.
