Overview of VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker 630A VCB

VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker 630A VCB is a type of circuit breaker where the arc quenching medium is a high vacuum. Unlike older breakers that used air, oil, or SF6 gas to extinguish the electrical arc, a VCB utilizes the superior dielectric properties of a vacuum to rapidly extinguish the arc when the contacts separate, thereby interrupting the current flow and protecting the electrical system.

Characteristics of VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker 630A VCB

Strong arc extinguishing ability: using vacuum medium to quickly extinguish the arc, with high breaking ability.

Safe and environmentally friendly: No fire or explosion risks, no greenhouse gas emissions.

Easy maintenance: Vacuum bubbles are maintenance free, with a long overall maintenance cycle and low workload.

Long lifespan: Both mechanical and electrical lifespan are very long.

Small size: Compact structure, saving space.”

Specifications of VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker 630A VCB

The VCB ZN63(VS1)-12 630A is a high voltage vacuum circuit breaker. It’s designed for indoor switchgear use. This breaker handles systems rated at 12 kilovolts. Its main continuous current rating is 630 amperes. This makes it suitable for many medium voltage applications.

The core component is its vacuum interrupters. These interrupters provide reliable arc quenching. They ensure safe current interruption. The breaker uses a spring-operated mechanism. This mechanism is known for its dependability. It provides fast closing and opening actions. Manual charging is standard. Electric charging options are also available.

Breaking capacity is crucial. This VCB interrupts fault currents up to 25 kiloamperes. It meets the IEC 62271-100 standard. This confirms its performance and safety. The design includes necessary safety interlocks. These prevent incorrect operation. The breaker fits standard switchgear compartments. Installation is straightforward.

Rated short-time withstand current is 25kA for 4 seconds. Rated peak withstand current reaches 63kA. These ratings ensure strength under fault conditions. The insulation level is high. It withstands 42kV power frequency voltage. It also withstands 75kV lightning impulse voltage. This provides good protection.

The mechanism is sturdy. It requires minimal maintenance. The vacuum interrupters have a long electrical life. They endure many switching operations. The breaker uses a standard withdrawable design. This aids installation and future servicing. Common dimensions apply. These fit typical switchgear panels. The VCB ZN63(VS1)-12 630A delivers dependable circuit protection. It offers proven performance in demanding environments.

Applications of VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker 630A VCB

The VCB ZN63(VS1)-12 630A High Voltage Switchgear Indoor Vacuum Circuit Breaker provides vital protection. This 630A circuit breaker handles high voltage systems up to 12kV. It fits inside switchgear panels. Its main job is protecting electrical equipment. It stops dangerous overloads and short circuits fast. This prevents damage. This prevents electrical fires.

Power plants use this breaker. It safeguards generators and transformers. Substations rely on it. It controls power flow between different grid sections. It isolates faulty lines quickly. This keeps the wider network stable. Factories need this breaker. It protects expensive motors and large machinery from electrical faults. Mines use it. Harsh environments demand reliable protection for critical mining equipment.

Renewable energy sites benefit too. Solar farms and wind installations use this VCB. It integrates generated power safely into the grid. It protects inverters and other sensitive equipment. Commercial buildings install it. Large offices, hospitals, and data centers require robust electrical protection for continuous operation. Their backup power systems often connect through this breaker.

The breaker uses vacuum technology. Vacuum inside the interrupter chamber extinguishes the arc. This happens when the contacts open under load. Vacuum interruption is very effective. It requires minimal maintenance. It offers a long service life. The design is compact. It saves valuable space inside switchgear. Operation is reliable. It performs consistently under demanding conditions. The breaker meets strict safety standards. It ensures personnel safety during operation and maintenance. It provides dependable circuit interruption. Electrical systems stay protected.
